CJ Hybrid Frame

This product is not available online. Please call to order.

SKU: TDK-CJHYBRID Category: Tag:



Don’t spend hours sanding, grinding and painting that old frame only to have it rust again. Throttle Down Kustoms’ frames are better than OE. Start with a solid frame for your project!

  • The TDK CJ Hybrid Frame is designed to use your CJ Body, Grill, Front Fenders, steering box, and gas tank then you can use TJ or (aftermarket TJ Style) Axles. It can also be set up for Long arm or Short arm style suspension. There is lots of custom options available on Hybrid Frame. The CJ Hybrid frame starts at $3800.


  • TDK frames are CNC mandrel bent for better than OEM precision.
  • Brackets are CNC laser cut out of 3/16″ and 1/4″ P&O steel plate.
  • Frames and brackets are hand welded in Montana.


  • Jeep frames are made from 2″x 4″ rectangular 3/16″ wall A500 tubing.
  • Brackets are made with 3/16″ and 1/4″ P&O steel.


  • Sag Steering Mounts n/c
  • Bumper Receiver Hitch $250
  • Bumper Receiver Hitch with Tire Carrier $675
  • Skid Plate Options start at $400
  • You can have the frame customized to meet your needs. Contact us to learn more.


  • All frames are shipped bare metal.

Additional information

Weight 800 lbs
Dimensions 170 × 57 × 24 in

Note: Weight and dimensions listed may not represent actual product weight or size and may only be used for shipping purposes.
